Y005 by Dixon Valve | Y Line Strainer | 20 x 20 Mesh Screen | 1" Female NPT x 1" Female NPT | Cast Iron

Y005 by Dixon Valve | Y Line Strainer | 20 x 20 Mesh Screen | 1" Female NPT x 1" Female NPT | Cast Iron

Save $42.98 Save $42.98
$107.45
$107.45 - $107.45
$107.45
$64.47
$64.47 - $64.47
$64.47

Dixon Valve
Y Line Strainer | Cast Iron
Specifications for Variant SKU: Y005 Dixon
Shape (Orientation): Y
Ends Configuration: \1\ Female NPT, 1\ Female NPT, Some Ends Match\
Material(s): Iron
Features:
  • Plug ported for blowdown service.
  • No replacement screens available.
Material:
  • Body: Cast Iron
  • Graphite gasket
Specification:
  • Working pressure: 500 PSI CWP; 250 PSI SWP
  • Maximum temperature: 406°F (208°C)
Cast Iron
Part Number		 Female NPT Mesh Type
Y001 1/4" 20 x 20 Mesh
Y002 3/8" 20 x 20 Mesh
Y003 1/2" 20 x 20 Mesh
Y004 3/4" 20 x 20 Mesh
Y005 1" 20 x 20 Mesh
Y006 1-1/4" 20 x 20 Mesh
Y007 1-1/2" 20 x 20 Mesh
Y008 2" 20 x 20 Mesh
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
